Name: Salt Dry and Wet Cycle Corrosion Salt Spray Test Machine Compound Salt Spray Test Chamber
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: AA120-480L
Price: 2000 USD
Availability: InStock

Casa. > prodotti > Camera Test ambientali >

Salt Dry and Wet Cycle Corrosion Salt Spray Test Machine Compound Salt Spray Test Chamber

salt spray test machine

compound salt spray chamber

dry wet corrosion tester

Luogo di origine:

Cina

Marca:

YUYANG

Certificazione:

Numero di modello:

AA120-480L

Contattaci

Richieda una citazione

Dettagli del prodotto

Dimensioni della sala di prova (WxLxH):

1200*1000*500

Dimensioni della macchina (LxLxH)(mm):

1410*880*1280

Temperatura di laboratorio:

NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C

Temperatura del saturatore:

NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C

Umidità:

85%~98%RH

Intervallo di temperatura:

± 0.5ºC

Sottovoce di salino:

1.0~2.0ml/80cm2/h

Alimentazione elettrica:

AC220V 50Hz

Evidenziare:

salt spray test machine

compound salt spray chamber

dry wet corrosion tester

Termini di pagamento e di spedizione

Quantità di ordine minimo

1 insieme

Prezzo

$2000

Imballaggi particolari

scatola di compensato

Tempi di consegna

5-10 giorni lavorativi

Termini di pagamento

T/T, L/C, Western Union

Capacità di alimentazione

200 set al mese

Prodotti correlati

Video

Large Capacity Salt Spray Corrosion Test Box for Various Material Testing

Ottieni il miglior prezzo

Video

Titanium Alloy Salt Fog Test Chamber for Hardware and Chemical Components

Ottieni il miglior prezzo

Video

Potenza elettronica industriale Tester di corrosione a spruzzo di sale continuo 220V Spruzzo salino per la macchina di prova con garanzia di 1 anno

Ottieni il miglior prezzo

Video

220V Electronic Salt Fog Corrosion Testing Machine Wave Style Salt Spray Aging Chamber 1 Year Warranty Salt Mist Resistance

Ottieni il miglior prezzo

Contattaci

8613265296009

sales13@yuyangtest.com

86-769-26622869

Contattaci ora

Descrizione del prodotto

Salt Dry and Wet Cycle Corrosion Salt Spray Test Machine

This multifunctional compound salt spray test chamber supports combined salt spray, dry and wet cycle corrosion testing for accelerated material aging assessment.

Product Overview

This salt spray test chamber is designed for evaluating the corrosion resistance of various surface-treated materials including paints, electroplating, organic and inorganic coatings, anode processing, and anti-rust oils after anti-corrosive treatment.

Construction Materials

Laboratory chamber constructed from 5mm thick PVC sheet, capable of withstanding temperatures up to 80°C
Laboratory closure features 6mm thick high-impact acrylic sheet
Reagent supplementary bottles include water level perspective windows with hidden viewing areas for easy cleaning and durability
Saturated air barrel manufactured from SUS #304 stainless steel for optimal insulation and pressure resistance
Laboratory basket features flat indexing frame with adjustable angles, ensuring uniform mist distribution across test specimens

Compliance Standards

GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201, H8502, H8610, K5400 Z2371

Technical Specifications

Model	YY120-480L
Test Room Size (W×L×H)	1200 × 1000 × 500 mm
Machine Size (W×L×H)	1410 × 880 × 1280 mm
Laboratory Temperature	NSS/ACSS: 35°C ± 1°C / CASS: 50°C ± 1°C
Saturator Temperature	NSS/ACSS: 35°C ± 1°C / CASS: 50°C ± 1°C
Humidity	85% ~ 98% RH
Temperature Range	± 0.5°C
Salt Spray Settling Rate	1.0 ~ 2.0 ml/80cm²/h
Power Supply	AC220V 50HZ
